Vertical two compartment fire cabinet

Vertical two compartment fire cabinet

  • Certificate: ISO
  • Standard: Refer to BS 5041
  • Capacity: Fire hose reel + layflat hose / Fire hose reel + extinguisher
  • Mounting: Wall surface / recessed
  • Surface: Red powder coating / bright SS

Product Details

Vertical fire cabinet has dual compartment for protecting both hose reel and layflat fire hose (or extinguisher). The cabinet is surface or recess mounted, with compact design for saving space and easy access for operation.

Available size

Content Capacity Dimension W x H x D (mm) Ref. No.
Swing hose reel + dry powder extinguisher 1″ x 30m + 3 x 6 kg 700 x 1400 x 250 FE9701
Swing hose reel + landing valve & layflat hose with branchpipe 1″ x 30m + 2.5″ x 30m 700 x 1400 x 300 FE9702
Swing hose reel + DP extinguisher & layflat hose with branchpipe 1″ x 30m + 1 x 6 kg & 2.5″ x 30m 800 x 1600 x 300 FE9703

Note:
1. For recessed type, it contains projection trim on the external face of cabinet with width 38mm.
2. The flank has knockout holes for easy connection to the pipeline.
3. Cabinets can be LPCB approved if they are with LPCB approved fire hose reels.
4. Other customized dimensions are also available.
