Grooved 90° reducing elbow is used to connect two pipes of different size by grooved connection, so to make the pipeline turn 90 degree for changing the fluid flow direction.
Available size
| Size (Inch / DN / mm) | Center to end, L(mm) | Ref. No. |
|---|---|---|
| 3″ x 2-1/2″ / 80 x 65 / 88.9 x 76.1 | 108 | G0501 (UL/FM) |
| 4″ x 2-1/2″ / 100 x 65 / 114.3 x 76.1 | 127 | G0502 (UL/FM) |
| 4″ x 3″ / 100 x 80 / 114.3 x 88.9 | 127 | G0503 (UL/FM) |
| 6″ x 4″ / 150 x 100 / 165.1 x 114.3 | 165 | G0504 (UL/FM) |
| 6″ x 4″ / 150 x 100 / 168.3 x 114.3 | 165 | G0505 (UL/FM) |
