K5.6 quick response vertical sidewall sprinkler is usually used in light and ordinary hazard occupancies. It is designed for installation in either the upright or pendent position, with its deflector discharging water parallel to the wall toward the center of the room.
Available size (Source 1 with UL/FM)
| Type | Temperature rating | Working pressure (psi) | Ref. No. |
|---|---|---|---|
| Vertical sidewall (VSW) | 135°F (57°C) | 175 | S1001 (UL/FM) |
| Vertical sidewall (VSW) | 155°F (68°C) | 175 | S1002 (UL/FM) |
| Vertical sidewall (VSW) | 175°F (79°C) | 175 | S1003 (UL/FM) |
| Vertical sidewall (VSW) | 200°F (93°C) | 175 | S1004 (UL/FM) |
| Vertical sidewall (VSW) | 286°F (141°C) | 175 | S1005 (UL/FM) |
Available size (Source 2 with FM)
| Type | Temperature rating | Working pressure (psi) | Ref. No. |
|---|---|---|---|
| Vertical sidewall (VSW) | 135°F (57°C) | 175 | S1021 (UL) |
| Vertical sidewall (VSW) | 155°F (68°C) | 175 | S1022 (UL) |
| Vertical sidewall (VSW) | 175°F (79°C) | 175 | S1023 (UL) |
| Vertical sidewall (VSW) | 200°F (93°C) | 175 | S1024 (UL) |
| Vertical sidewall (VSW) | 286°F (141°C) | 175 | S1025 (UL) |
