Grooved drain cap with eccentric hole

Grooved drain cap with eccentric hole

Category
  • Certificate: UL Listed / FM Approved
  • Standard: ANSI / UL 213C
  • Material: Ductile iron ASTM A536, 65-45-12
  • Eccentric hole: Female thread, NPT / BSPT
  • Rated pressure: 300 ~ 500 psi
  • Surface: Red painting / hot dip galvanized

Product Details

Grooved drain cap with eccentric hole is used to mount at the pipe end by groove connection, with a eccentric hole for drainage.

Available size

Size (Inch / DN / mm) End to end (mm) Ref. No.
2″ x 1″ / 50 x 25 / 60.3 x 33.7 25 G4201 (UL/FM)
2″ x 1-1/2″ / 50 x 40 / 60.3 x 48.3 25 G4202 (UL)
2-1/2″ x 1″ / 65 x 25 / 73.0 x 33.7 25 G4203 (UL/FM)
2-1/2″ x 1″ / 65 x 25 / 76.1 x 33.7 24 G4204 (UL/FM)
2-1/2″ x 1-1/2″ / 65 x 40 / 76.1 x 48.3 25 G4205 (UL/FM)
2-1/2″ x 2″ / 65 x 50 / 76.1 x 60.3 25 G4206 (UL/FM)
3″ x 1″ / 80 x 25 / 88.9 x 33.7 24 G4207 (UL/FM)
3″ x 1-1/2″ / 80 x 40 / 88.9 x 48.3 24 G4208 (UL/FM)
3″ x 2″ / 80 x 50 / 88.9 x 60.3 24 G4209 (UL/FM)
4″ x 1″ / 100 x 25 / 114.3 x 33.7 27 G4210 (UL/FM)
4″ x 1-1/2″ / 100 x 40 / 114.3 x 48.3 27 G4211 (UL/FM)
4″ x 2″ / 100 x 50 / 114.3 x 60.3 27 G4212 (UL/FM)
5″ x 1-1/2″ / 125 x 40 / 139.7 x 48.3 27 G4213 (UL/FM)
5″ x 2″ / 125 x 50 / 139.7 x 60.3 27 G4214 (UL/FM)
6″ x 1-1/2″ / 150 x 40 / 165.1 x 48.3 27 G4215 (UL/FM)

Note: Please download our catalog for more available sizes.
