Grooved 22.5° elbow

Grooved 22.5° elbow

Category
  • Certificate: UL Listed / FM Approved
  • Standard: ANSI / UL 213C
  • Material: Ductile iron ASTM A536, 65-45-12
  • Type: Standard radius
  • Rated pressure: 300 ~ 500 psi
  • Surface: Red painting / hot dip galvanized

Product Details

Grooved 22.5° elbow is used to connect two pipes by groove connection, so to make the pipeline turn 22.5 degree for changing the fluid flow direction.

Available size

Size Standard radius (mm) Ref. No.
1″ / DN25 / 33.7mm 41 G0801
1-1/4″ / DN32 / 42.4mm 45 G0802
1-1/2″ / DN40 / 48.3mm 45 G0803
2″ / DN50 / 60.3mm 48 G0804
2-1/2″ / DN65 / 73.0mm 51 G0805
2-1/2″ / DN65 / 76.1mm 51 G0806
3″ / DN80 / 88.9mm 57 G0807
4″ / DN100 / 114.3mm 73 G0808
5″ / DN125 / 139.7mm 73 G0809
6″ / DN150 / 165.1mm 79 G0811
6″ / DN150 / 168.3mm 79 G0812
8″ / DN200 / 219.1mm 98 G0813
10″ / DN250 / 273.0mm 111 G0814
12″ / DN300 / 323.9mm 124 G0815
