PVC coated FMC (Flexible metal conduit) has a spiral shape that allows it to bend easily, withstand impact and crushing force. Both Halogen free type and standard type are available.
Available size
| Trade size | Outer diameter (mm) | Inner diameter (mm) | Min bend radius (mm) | Ref. No. |
|---|---|---|---|---|
| 3/8″ | 17.0 | 12.0 | 50 | C2021 |
| 1/2″ | 21.0 | 16.0 | 75 | C2022 |
| 3/4″ | 26.0 | 20.0 | 100 | C2023 |
| 1″ | 32.0 | 25.0 | 125 | C2024 |
| 1-1/4″ | 40.0 | 32.0 | 160 | C2025 |
| 1-1/2″ | 47.0 | 38.0 | 190 | C2026 |
| 2″ | 61.0 | 51.0 | 255 | C2027 |
| 2-1/2″ | 72.0 | 63.0 | 320 | C2028 |
| 3″ | 88.0 | 75.0 | 380 | C2029 |
| 4″ | 114.0 | 100.0 | 510 | C2030 |
