Malleable iron reducing tee (Bull head tee) has a T shape to get its name. The branch outlet has a larger size than the main outlets, and it is used to create a branch pipeline to 90-degree direction.
Available size (Class 150)
| Size | A (mm) | B (mm) | Ref. No. |
|---|---|---|---|
| 1/2″ x 1/2″ x 3/4″ / DN15 x DN15 x DN20 / 21.3mm x 21.3mm x 26.7mm | 31.0 | 30.5 | M6110 (UL/FM) |
| 1/2″ x 1/2″ x 1″ / DN15 x DN15 x DN25 / 21.3mm x 21.3mm x 33.4mm | 34.6 | 32.0 | M6113 (UL/FM) |
| 3/4″ x 3/4″ x 1″ / DN20 x DN20 x DN25 / 26.7mm x 26.7mm x 33.4mm | 36.8 | 34.8 | M6114 (UL/FM) |
| 3/4″ x 3/4″ x 1-1/4″ / DN20 x DN20 x DN32 / 26.7mm x 26.7mm x 42.2mm | 41.2 | 36.8 | M6117 (ISO) |
| 1″ x 1″ x 1-1/4″ / DN25 x DN25 x DN32 / 33.4mm x 33.4mm x 42.2mm | 42.4 | 40.1 | M6118 (UL/FM) |
| 1″ x 1″ x 1-1/2″ / DN25 x DN25 x DN40 / 33.4mm x 33.4mm x 48.3mm | 45.7 | 41.9 | M6123 (UL/FM) |
| 1″ x 1″ x 2″ / DN25 x DN25 x DN50 / 33.4mm x 33.4mm x 60.3mm | 51.3 | 48.9 | M6129 (UL/FM) |
| 1-1/4″ x 1-1/4″ x 1-1/2″ / DN32 x DN32 x DN40 / 42.2mm x 42.2mm x 48.3mm | 47.8 | 46.2 | M6124 (UL/FM) |
| 1-1/4″ x 1-1/4″ x 2″ / DN32 x DN32 x DN50 / 42.2mm x 42.2mm x 60.3mm | 53.3 | 48.3 | M6130 (UL/FM) |
| 1-1/2″ x 1-1/2″ x 2″ / DN40 x DN40 x DN50 / 48.3mm x 48.3mm x 60.3mm | 54.9 | 51.3 | M6131 (UL/FM) |
| 2″ x 2″ x 2-1/2″ / DN50 x DN50 x DN65 / 60.3mm x 60.3mm x 73.0mm | 66.0 | 60.7 | M6137 (UL/FM) |
